5.1 MODULE 1 - S IGNAL I NPUT P ARAMETERS ( 1-INP )
1-INP
SEL
PARAMETER MENU
Pro
tYPE
Thermocouple
Type
CJC
Cold Junction
Compensation
SCALE
Temperature
Scale
dECPt
Display
Decimal Point
OFSEt
Display Offset
Value
FILtr
Filter Setting
bANd
Filter Band
USrIN
User Input
Function
U-ASN
User Input
Assignment
tYPE
?
?
tc-J
THERMOCOUPLE TYPE
SELECTION TC TYPE SELECTION
tc-t T tc-S
tc-E E tc-b
J
tc-j
tc-n
TC TYPE
S
B
N
Filter values represent no filtering (0), up to heavy filtering (3). A value of 1
for the filter uses 1/4 of the new input and 3/4 of the previous display to
generate the new display. A filter value of 2 uses 1/8 new and 7/8 previous. A
filter value of 3 uses 1/16 new and 15/16 previous.
?
yES
?
tc-K K VOLt
tc-r R
Select the thermocouple type used for the application. The appropriate curve
will be automatically loaded for the selected type.
Selecting VOLt displays the millivolt input signal with 10 μV resolution.
COLD JUNCTION COMPENSATION
CJC ?
yES NO
FILTER BAND
bANd ?
00 to 199 display units
10
The filter will adapt to variations in the input signal. When the variation
exceeds the input filter band value, the filter disengages. When the variation
becomes less than the band value, the filter engages again. This allows for a
stable readout, but permits the display to settle rapidly after a large process
change. The value of the band is in display units, independent of the Display
Decimal Point position. A band setting of ‘0’ keeps the filter permanently
engaged at the filter level selected above.
This parameter enables or disables internal cold junction compensation. For
most applications, cold junction compensation should be enabled ( yES ). This
parameter does not appear if tYPE = VOLt .
USrIN
?
USER INPUT FUNCTION
?
d-SEL Display Triggered)
d-LEV Display Triggered) Level
COLOr Backlight Color
OFSEt ?
TEMPERATURESCALE
SCALE ?
°F °C
°F
Select the temperature scale. This selection applies for the Input, MAX and
MIN displays. This parameter does not appear if tYPE = VOLt .
DISPLAY DECIMAL POINT
dECPt ? 0 0.0
? 0
Select the decimal point location for the desired display resolution. This
selection applies for the Input, MAX and MIN displays. This parameter does
not appear if tYPE = VOLt or for types R, S or B thermocouples which have a
fixed 1 degree resolution.
DISPLAY OFFSET VALUE
-999 to 9999
? 0
The temperature display can be corrected with an offset value. This can be
used to compensate for probe errors, errors due to variances in probe placement
or adjusting the readout to a reference thermometer.
? NO
DISPLAY MODE
NO No Function
P-Loc Program Mode Lock-out
rESEt Reset (Edge triggered)
d-HLd Display Hold
Select
(Edge
Intensity
(Edge
(Edge Triggered)
Print Print Request
P-r5t Print and Reset
rSt-1 Setpoint 1 Reset
rSt-2 Setpoint 2 Reset
rSt12 Setpoint 1 and 2 Reset
DESCRIPTION
User Input disabled.
See Programming Mode Access chart
(Module 3).
Resets the assigned value(s) to the
current input value.
Holds the assigned display, but all other
meter functions continue as long as
activated (maintained action).
Advance once for each activation.
Increase intensity one level for each
activation (backlight version only).
Change backlight color with each
activation (backlight version only).
Serial transmit of the active parameters
selected in the Print Options menu
(Module 5).
Same as Print Request followed by a
momentary reset of the assigned value(s).
Resets setpoint 1 output.
Resets setpoint 2 output.
Reset both setpoint 1 and 2 outputs.
USER INPUT ASSIGNMENT
?
FILTER SETTING
FILtr ?
0,1 2 3
1
If the displayed temperature is difficult to read due to small process
variations or noise, increased levels of filtering will help to stabilize the display.
Software filtering effectively combines a fraction of the current input reading
with a fraction of the previous displayed reading to generate the new display.
7
U-ASN ? HI HI-LO
? dSP LO dSP
Select the value(s) to which the User Input Function is assigned. The User
Input Assignment only applies if a selection of reset, display hold, or print and
reset is selected in the User Input Function menu.
